T45 T51 Adapter Length 770mm Bench Drilling Rock Drill Parts Extractor Drifter Shank Adapter
Shank Adapter For Atlas Copco COP 1840EX Drifter
| Thread | Part Number | Length(mm) | Diameter(mm) | Weight(kg) | Flushing Tube(mm) |
| T45(1 3/4'') | 414832480 | 770 | 60 | 10.8 | - |
| T51(2'') | 414832481 | 770 | 60 | 10.9 | - |
Shank adapter ATLAS COPCO COP 1840 extractor T-45,
length: 770mm, diameter: 60mm,
equivalent to atlas product No. 90516305, product code 436-13402.10
Shank adapter ATLAS COPCO COP 1840 extractor T-51, length: 770mm, diameter: 60mm,
equivalent to atlas product No. 90516317, product code 437-13402.10
In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.
Basic Information - KSQ shank adapter equivalent to:
Atlas Copco, Boart, Furukawa, Gardner-Denver, Ingersoll-Rand, Montabert, SIG, Shank Adapter
Competitive Advantage
- High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.
- The accurate dimension of thread perfectly matches the rock drill
- Work reliably and very cost-effective
Applications
• Bolting, drifting
• Bench drilling
• Production drilling
Specification:
| Shank Adapter for Altas Copco 1840 EX |
| Thread | Diameter | Length | Flushing | Weight | Part Number |
| mm | mm | kg |
| T51 | 60 | 770 | | 10.9 | 41482481 |
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that have to be followed
- Significant differences in the way people work, mostly due to physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
