Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools

Name: Furukawa HD 609 Forging Shank Adapter Mining Quarrying Hammer Drilling Tools
Brand: MIROC
Price: 1 USD

China Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools wholesale

Brand Name : MIROC

Model Number : Shank adapter

Certification : ISO

Place of Origin : China

MOQ : 50

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20000 pieces per month

Delivery Time : 1-20 days

Packaging Details : Wooden Plate

Material : Tungsten Carbide

Color : Based on Customer requirements

Processing : Forging

Advantage : OEM.

Price : negotiation

Contact Now

Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools

Description

In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.

• Used in top hammer drilling systems

Applications

• Underground mining
• Tunneling
• Quarry

Competitive Advantage

High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance

Specification
Part Number	Product Code and Brief Description	Thread	Length (mm)	Weight (kg)
4148301207	HL 1500-S80 [G1]	ST58	635	18.8
4148301208	HL 1500-S80 [G2]	ST58	635	18.9
4148301209	HL 1500-SPE90 [G1]	ST58	635	21.8
4148301210	HL 1500-SPE90 [G2]	ST58	635	21.9

Packaging & Shipping

Wooden boxes or Carton boxes

Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools

Rock Button Bit

T38 button bit
	Bit Dia.	Buttons and Size (mm)		Flushing Hole		Weight
	mm	Front	Gauge	Front	Side	kg
1	64	3×10, 1×10	6×11	3	-	1.7
2	70	3×10, 1×10	6×12	3	-	1.8
3	76	3×11, 1×11	6×12	3	1	2.6
4	89	3×11, 2×11	6×13	3	1	3.3
R38 button bit
	Bit Dia.	Buttons and Size (mm)		Flushing Hole		Weight
	mm	Front	Gauge	Front	Side	kg
1	64	3×11	6×12	3	-	1.8
2	70	3×10, 1×10	6×12	3	-	1.8
3	76	3×11, 1×11	6×12	2	-	2.6
4	89	4×13, 1×13	8×13	4	-	3.3
R32 button bit
	Bit Dia.	Buttons and Size (mm)		Flushing Hole		Weight
	mm	Front	Gauge	Front	Side	kg
1	41	2×8	5×9	1	1	0.7
2	43	2×9	5×10	1	1	0.7
3	45	2×9	5×11	1	1	0.8
4	48	2×9	5×11	1	1	0.9
5	51	2×10	5×11	1	1	1
6	57	3×9	6×11	3	-	1.3
7	64	3×11	6×12	3	-	1.6
8	70	4×11	8×11	2	-	2.6
9	76	4×11	8×11	2	-	2.8
R28 button bit
	Bit Dia.	Buttons and Size (mm)		Flushing Hole		Weight
	mm	Front	Gauge	Front	Side	kg
1	37	2×7	5×9	1	1	0.5
2	38	2×7	5×9	1	1	0.6
3	41	2×8	5×9	1	1	0.7
4	43	2×9	5×9	1	2	0.8
5	45	2×9	5×10	1	2	0.9
6	48	2×9	5×11	1	2	1
R25 button bit
	Bit Dia.	Buttons and Size (mm)		Flushing Hole		Weight
	mm	Front	Gauge	Front	Side	kg
1	33	2x7	5x7	1	1	0.4
2	35	2x7	5x8	1	1	0.4
3	38	2x7	5x8	1	1	0.5
4	41	2x8	5x9	1	2	0.6
5	45	2x8	5x10	1	2	0.6

Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools

Our Services

KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

Hazardous environment
Acts, regulations, and other government guidelines that has to be followed
Significant differences in the way people work, mostly due o physical constraints
Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.

Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools

Product Tags:

drill bit shank adapter

threaded shank drill bit adapter

Furukawa HD 609 Forging Shank Adapter , Mining / Quarrying Hammer Drilling Tools Images
